HDGC3932
Technical Parameters – HDGC3932 Battery Cell Activator
Electrical Specifications
Supported Battery Voltage Range: 1.0 V – 16 V
Nominal Operating Voltage Modes:
2 V batteries: 1.7 V – 2.4 V
6 V batteries: 5.4 V – 7.2 V
12 V batteries: 10.8 V – 14.5 V
Maximum Output Current:
2 V mode: 100 A
6 V mode: 60 A
12 V mode: 30 A
Working Modes: Activation / Constant‑Current / Constant‑Voltage / Float‑Charge
Measurement & Accuracy
Voltage Measurement Accuracy: ±0.5% FS + 0.1 V
Current Measurement Accuracy: ±1% FS + 0.1 A
Voltage Resolution: 0.01 V
Current Resolution: 0.01 A
Self‑Calibration: Supported for high‑accuracy measurement
Display & Interface
Screen: 7‑inch LCD Touchscreen (1024×600 resolution)
Data Communication: USB
Curve & Waveform Display: Supports real‑time graphing and historical data viewing
Data Storage
Internal Storage: 16 GB
External Storage: 32 GB USB disk (included)
Data Export: Excel / Word report generation via PC software
Protection & Safety
Protection Modes: Over‑current / Short‑circuit / High‑temperature / Reverse polarity
Temperature Protection: Auto‑shutdown above 75 °C
Abnormal Protection: Power line drop / Mains cable drop
Safety Standard: EN610950 compliant
Pressure Resistance:
Input–Housing: 2200 V DC (1 min)
Input–Output: 2200 V DC (1 min)
Output–Housing: 700 V DC (1 min)
Working Environment
Cooling Method: Air‑cooled
Operating Temperature: −5 °C to 50 °C
Storage Temperature: −40 °C to 70 °C
Humidity: 0–90% RH (at 40 °C)
Maximum Altitude: ≤ 4000 m
Power Requirements
Input Voltage: 230 VAC
Frequency: 45–65 Hz
Physical Specifications
Dimensions: 390 × 230 × 290 mm
Weight: 10 kg
Included Accessories
Power Cable
Voltage Acquisition Line
Ground Cable
USB Disk (Software Included)
Operational Manual
Test Report
Product Certificate
